Hardware
xIL PRODUCTS FOR COMPLETE TEST AND EVALUATION OF IOT AND NETWORKED DIGITAL SYSTEMS.
Product Applications
Cost effective, modular, solutions for rapid development of simulation and test equipment across a wide range of xIL applications:
Open and Closed Loop T&E of complex HW-SW systems
V&V of heterogeneous, networked systems of ECUs, sensors, actuators, and edge computing devices
Network and Communications Bus testing
Product features
Built for flexibility and ease of use:
ExSignal references are maintained throughout the architecture
Components are designed for interoperability
Modular and scalable for use across the entire test lifecycle
Standardized connectivity and cabling
Optimized, modular, load and failure insertion solutions
Technical Details
The Orangewire DET is based on the National Instruments’ 12-slot SLSC chassis. The integrated DET design provides signal and power bus continuity through the chassis, and allows for connectivity with National Instruments PXI and cRIO products from the rear.
Signal and power routing is achieved through four bus lines, which are carried through the HIL backplane. The backplane additionally provides an intelligent communications bus for system control. Chassis to chassis expandability is achieved through deterministic Ethernet or reflective memory, allowing systems to scale from desktop to large integration test racks.
The SLSC architecture from NI accommodates up to twelve (12) interchangeable load, signal conditioning, or failure insertion boards. The design allows optimized, application targeted chassis to be constructed from a broad catalog of SLSC compliant hardware.
Products
OW-901-32
32-Channel Digital I/O Scaling
The OW-901-32 is a 32-channel bi-directional digital signal conditioning card that scales input and output digital signals from TTL lab equipment to application voltage ranges from 3 to 60 V.….
OW-701-16
16-Channel Current Sense
The OW-701-16 is a 16-channel bi-directional current measurement card based on Hall-Effect sensors used to measure the current between an electrical source and a load. The channels support 17, 27, and 55…
OW-902-8
8-Channel Wheel Speed Simulator
The OW-902-8 is an 8-channel digital signal conditioning card that acts as a front-end signal conditioner for NI real-time logic modules to simulate 2-wire wheel speed signals. When running a software model…
OW-130
12-Slot Signal Adapter Failplane
The OW-130 is a 12-slot midplane that provides common power and signal references to other OrangeWire load, FIU, and signal conditioning boards. The midplane features eight power rails…
OW-402-32
32-Channel Sensor and Small Load Fault Insertion
The OW-402-32 is a 32-channel FIU card that provides the ability to simulate electrical faults of small loads and simulated signals with ability to support up to 1 A….
OW-403-16
16-Channel Fault Insertion
The OW-403-16 is a 16-channel FIU card that provides the ability to simulate electrical faults of loads with ability to support up to 17 A per channel. This module is designed.….
OW-206-32
32-Channel Load Board
The OW-206-32 is a 32-channel load card that provides the ability to connect up to 15 W electrical loads in laboratory or production test…
OW-503-4
4-Channel Power Switch
The OW-503-4 is a 4-channel intelligent power switch that controls four channels of power into or out of the SLSC Chassis. The board is used to provide…
